CPU | Model: Rockchip RK3399 Number of Cores: big.LITTLE, 64-bit Dual Core Cortex-A72 + Quad Core Cortex-A53 Frequency: Cortex-A72(up to 2.0GHz), Cortex-A53(up to 1.5GHz) |
GPU | Mali-T864 GPU,supports OpenGL® ES1.1/2.0/3.0/3.1, OpenCL™, DX11, and AFBC |
VPU | 4K VP9 and 4K 10bits H265/H264 60fps decoding, Dual VOP, etc |
Memory | 1GB DDR3-1866 |
Storage | eMMC: no Onboard eMMC, but has a eMMC socket MicroSD Slot: MicroSD*1 for external storage up to 128GB |
Connectivity | Ethernet: Native Gbps Ethernet WiFi: 802.11 b/g/n, Bluetooth 4.0 combo module Antenna*1: IPX Connector |
Audio | Audio Output: HDMI |
Video Input | one 4-Lane MIPI-CSI, up to 13MPix/s |
Video Output | HDMI*1: HDMI 2.0a, supports 4K@60Hz,HDCP 1.4/2.2 |
USB | USB 3.0*1: USB 3.0 Type-A ports USB Type-C*1: Supports USB2.0 OTG and Power input USB 2.0*2: USB 2.0 Host, one is Type-A, the other is 2.54mm header |
Pin-header | GPIO1: 40pin ,Female connector (M50-4302045) 2 X 3V I2C, 1x 3V UART/SPI, 1 x SPDIF_TX, up to 8 x 3V GPIOs PCIe x2 PWM x1, PowerKey GPIO2: 1 x 1.8V 8ch-I2S GPIO3: debug uart, 3V level, 1500000bps USB 2.0 x1 |
LED | Power LED(Red)*1 GPIO Controlled LED(Green)*1 |
Others | RTC Battery: 2 Pin 2.54mm pitch through-hole pad Working Temperature: -20℃ to 70℃ |
Power | DC 5V/3A |
OS Support | Android 8.1 (eMMC Module required) Lubuntu 16.04 (32-bit) FriendlyCore 18.04 (64-bit) FriendlyDesktop 18.04 (64-bit) FriendlyWrt 19.07-snapshot (64-bit) Armbian (3rd) |
Kernel version | Linux-4.4-LTS U-boot-2014.10 |
PCB | 8 Layer |
Dimension | 60*45mm |
Weight | 30.25g |
Optional Accessories
-
NanoPi NEO4 Heat Sink
($5.99) -
5V 4A Power Adapter
($8.99) -
German Plug Adapter
($5.99) -
USB Type-C to USB-A Male 2.0 Cable - 30cm
($2.99) -
SanDisk 16GB EDGE A1 U1 Class 10 Micro SD SDHC MicroSD Memory Card
($7.99) -
eMMC Module - 16GB eMMC Module
($12.00) -
13.2MP MIPI Camera Module
($25.00)
Related Resources
WIKI: http://wiki.friendlyarm.com/wiki/index.php/NanoPi_NEO4
